Mass Flow Controllers

Proportion-Air manufactures complete closed-loop electronic mass flow controllers that have quick response and the ability to control flow rates from 2 SCFH to 250 SCFM.

These mass flow controllers are industrial quality and can be mounted in any orientation with the ability to withstand intense vibrations while continuing to control flow. Our flow control assemblies are subject to a 10:1 turndown ratio (inquire about 20:1) meaning that we will control flow at 10% to 100% of the range with ±0.25% repeatability. The gases we can control include: Air, Argon, Carbon Dioxide, Helium (not bubble tight), Nitrous Oxide, Nitrogen and Oxygen. Mass Flow Controllers with <10ms Response Time.

Request Quote
Mass Flow Controllers

FQPV2 | F-Series


< 1 SCFM Flow Control

Mass Flow Controllers

FQB3 | F-Series


< 30 SCFM Flow Control

Mass Flow Controllers

FQB2 | F-Series


< 250 SCFM Flow Control

Mass Flow Controllers

FCV


1″ Flow Control Valve

The building block for all of our mass flow controllers is the F-series mass flow transducer. The F-series uses high speed differential pressure technology to produce an electrical signal proportional to the mass flow of air – or, whatever gas you want to control. This high speed flow signal is able to be used by a wide variety of Proportion-Air mass flow control valves to close the loop directly around air flow. Based on your required flow rate, the F-series mass flow transducer is matched to the appropriate flow control valve and then calibrated specifically to your exact flow range.

Each electronic flow control valve constantly compares your command signal to the transducer signal of the F-Series flow transducer. The control valve then opens or closes (almost instantaneously) to maintain the commanded flow rate.

Mass Flow Controllers

F-Series


Mass Flow Transducer

Three

Flow Control Models

with subtle differences and important implications

LEARN MORE

FR

PRESSURE REGULATED

Requires a known and fixed regulated supply pressure to maintain calibration

FP

PRESSURE COMPENSATED

Compensates for fluctuations in inlet pressure (up to 50%) to maintain calibration

FA

ATMOSPHERIC

Requires output port open to atmosphere. Most commonly used in cylinder speed control.

REQUEST QUOTE

Most quotes within 6 hours of understanding your needs
